KDA5633
Verfügbarkeit für Abholungen konnte nicht geladen werden
Fast & Free Shipping
Fast & Free Shipping
Add some general information about your delivery and shipping policies.
Warranty
Warranty
Display general product information or specific product information using metafields.
Download Files
- KDA5633 Download
KDA5633
- Overview
- Applications
- Specification
- Comparison
- Reviews
- FAQs
Product Overview
Applications
-
Wireless communication systems
-
Satellite communication
-
Radar system
-
Test and measurement equipment
-
Internet of Things (IoT) equipment
Operating frequency
DC-20.0GHz
Insertion loss
3.5dB@20GHz（Typical value）
Attenuation range
5-35dB
Attenuation accuracy
0.3dB（Typical value）
Attenuate additional phase shift
±3°
Return loss
−15dB（Typical value）
Electricity supply
−5V/3.5mA（Typical value）
Linear workspace
≤26dBm
Product Comparison
| Produktfacette | |||
|---|---|---|---|
| Operating frequency | |||
| Operating frequency | DC~20GHz | 2.4GHz/5.8GHz | 2300M~2500MHz |
| Insertion loss | |||
| Insertion loss | 3.5dB@20GHz (typical value) | 8dB/10dB | 40dB |
| Attenuation range | |||
| Attenuation range | 0.5~31.5dB | 5V/100mA(typical value) | 28V/5A |
| Attenuation accuracy | |||
| Attenuation accuracy | 0.1dB (typical value) | - | 30W |
| Attenuate additional phase shift | |||
| Attenuate additional phase shift | -15dB (typical value) | - | 130*50*16±0.1mm |
| Return loss | |||
| Return loss | -5V/7.2mA (typical value) | - | - |
| Electricity supply | |||
| Electricity supply | ≤25dBm | - | - |
| Linear workspace | |||
| Linear workspace | 30ns | - | - |
